Standard Features and Equipment
Stronghaul EATF-DT Brochure.PDF
-Standard Equipment-
|
Frame Tubes: 8.00” x 3.00” x .250”w 6061-T6 |
Wheels: Black Modular-Style Wheels, R15” x 6” W, 6 Lug on 5.5” BHP - DT52 |
|
Hitch Tubes: 6.00” x 2.00” x .250”w 6061-T6 |
Wheels: Black Modular Style Wheels, R16” x 8” W, 8 Lug on 6.5” BHP - DT70 |
|
Floor Channels: 3.00” x 1.50” x .190”w 6061-T6 on 16” centers |
Harness Plug: 7-Way RV-Style Connector with Break-away Kit |
|
Stake Pockets: .250” (3.5”x1.5” ID) |
Lighting: LED Lighting Pkg with Sealed Harness |
|
Rub Rail: .250” x 3.00” 6061-T6 |
Decking: 2x8 No.1 Grade, Douglas Fir/Larch Plank Floor |
|
Dovetail Section: 2’ with 3” Drop (Length of trailer includes DT section) |
Safety Chains: 3/8” x 35” Chains, 16.2K lb. Rating, with Safety Latch |
|
Axles: 5200lb Straight, E-brake, Slipper Leaf Spring, Dexter Axles - DT52 |
Fenders: Tip Out Fenders with Rubber Latch |
|
Axles: 7000lb Straight, E-brake, Slipper Leaf Spring, Dexter Axles - DT70 |
Stabilizer Stands: Fold Up Stabilizer Stands – Pocket Ramp Model Only |
|
Suspension: HD Slipper Style, Greaseable Equalizer |
Lashing Rings: -4k lb, Zinc Plated (8 Rings on 20’ model, 10 on 22’/24’, 12 on 26’) |
|
Axle Mounting Brackets: .250” Hangers & Main Brkt, Galv. with Poly Tape |
Deck to Ground Height: 26” |
|
Coupler: 2-5/16” Adjustable Ball Coupler, 4” of Height Adjustment |
Bumper to Ground Height: 23” |
|
Jack: 9,500lb, Drop Leg Jack with Removable Side Wind Handle |
Coupler to Ground Height: 16” When Level (18” or 14” with adjustment) |
|
Spare Tire Mount: 13.5” Front Rail with Mount (side MNT with toolbox opt) |
Ramp Loading Angle: 15 Degrees |
|
Tires: Goodride or Westlake ST225/75R15 6-ply Radial Tires on - DT52 |
Ramp Option 1: Pocket Style, 7,000lb CAP/Ea, 78” L x 14” W |
|
Tires: Goodride or Westlake ST235/80R16 10-ply Radial Tires - DT70 |
Ramp Option 2: Dual Beaver Tail Ramps, 8,000lb CAP/Ea, 60” L x 32” W |
-GVWR: 14,000lbs or 10,000lbs
